3541L-S08-R datasheet(3/6 Pages) UTC

3 / 6 page

3541

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

3 of 6

www.unisonic.com.tw

QW-R502-035.C

ABSOLUTE MAXIMUM RATINGS

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VDD

Output Short-Circuit Duration (TA=25°C, PD=1W)

tSC(O)

Junction Temperature

150

°C

Operating Temperature

TOPR

-40 ~ +85

°C

Storage Temperature

TSTG

-65 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient (Note)

DIP-8

θJA

108

°C/W

SOP-8

210

Junction to Case

DIP-8

θJC

°C/W

SOP-8

Note: θJA is measured with the component mounted on a high effective thermal conductivity test board in free air.

ELECTRICAL CHARACTERISTICS

(VIN=0dBV, VCC=5V, TA=25°C, f=1kHz, RL=32Ω, unless otherwise specified.)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX UNIT

Supply Voltage

VDD

3.0

5.0

6.0

Mute Terminal Voltage

VTM

0.3

0.7

1.6

Quiescent Current

VIN = 0VRMS

3.5

Mute Current

IMUTE

200

μA

Voltage Gain

GVCL

VIN=1VRMS, f =1kHz, RL=32Ω

-2

Differential Channel Voltage Gain

ΔGVCL

-0.5

0.5

Channel Separation

f =1 kHz

-90

-92.5

Mute Attenuation

ATT

VIN = 1Vrms, f =1 kHz, Mute=L

Ripple Rejection

FRR =100Hz, VRR = -20dBV

Output Noise Voltage

VNO

BW = 20~20kHz, VIN=0VRMS

-93

-85

dBV

Total Harmonic Distortion

THD

BW<120 kHz

0.03

0.1

Rated Output Power 1

PO1

THD+N=0.1%, BW＜120kHz

RL=32Ω

Rated Output Power 2

PO2

RL=16Ω

105

110
