2 / 4 page ![]() UML2502 Power MOSFET UNISONICTECHNOLOGIESCO.,LTD 2 of 4 www.unisonic.com.tw QW-R502-227.B ABSOLUTE MAXIMUM RATINGS (TA =25℃, unless otherwise specified) PARAMETER SYMBOL RATINGS UNIT Drain-Source Voltage VDSS 20 V Gate-Source Voltage VGSS ±12 V Continuous Drain Current VGS=4.5V ID 4.2 A Pulsed Drain Current (Note 2) IDM 33 A 1.25 W Maximum Power Dissipation Linear Derating Factor PD 0.01 W/℃ Junction Temperature TJ +150 ℃ Storage Temperature TSTG -55 ~ +150 ℃ Note: 1. 2. Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied. Pulse width limited by TJ(MAX) THERMAL DATA PARAMETER SYMBOL RATINGS UNIT Junction to Ambient θJA 75 ~ 100 ℃ /W ELECTRICAL CHARACTERISTICS (TJ =25℃, unless otherwise specified) PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT OFF CHARACTERISTICS Drain-Source Breakdown Voltage BVDSS VGS=0V, ID=250μA 20 V Drain-Source Leakage Current IDSS VGS=0V, VDS=16V 1.0 µA Gate-Source Leakage Current IGSS VGS=±12V, VDS=0V ±100 nA Breakdown Voltage Temperature Coefficient ΔBVDSS/ΔTJ Reference to 25 , ℃ ID=1mA 0.01 V/℃ ON CHARACTERISTICS Gate Threshold Voltage VGS(TH) VDS=VGS, ID=250µA 0.6 1.2 V VGS=4.5V, ID=4.2A 35 45 Drain-Source On-State Resistance (Note) RDS(ON) VGS=2.5V, ID=3.6A 50 80 mΩ DYNAMIC CHARACTERISTICS Input Capacitance CISS 740 pF Output Capacitance COSS 90 pF Reverse Transfer Capacitance CRSS VGS=0V, VDS=15V, f=1.0MHz 66 pF SWITCHING PARAMETERS Turn-ON Delay Time (Note) tD(ON) 7.5 ns Turn-ON Rise Time tR 10 ns Turn-OFF Delay Time tD(OFF) 54 ns Turn-OFF Fall-Time tF VDS=10V, RG=6Ω, RD=10Ω, ID=1.0A 26 ns Total Gate Charge (Note) QG 8.0 12 nC Gate Source Charge QGS 1.8 2.7 nC Gate Drain Charge QGD VGS=5.0V, VDS=10V, ID=4.0A 1.7 2.6 nC SOURCE- DRAIN DIODE RATINGS AND CHARACTERISTICS Diode Forward Voltage VSD VGS=0V, IS=1.3A, TJ=25℃ (Note) 1.2 V Maximum Pulsed Drain-Source Diode Forward Current ISM 33 A Maximum Continuous Drain-Source Diode Forward Current IS 1.3 A Reverse Recovery Time tRR 16 24 ns Reverse Recovery Charge QRR IF=1.3A, dI/dt=100A/μs, TJ=25℃ (Note) 8.6 13 nC Notes: Pulse width ≤ 300μs; duty cycle ≤ 2%. |
|
|
