ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

+6

V

+6

V

1.33

W

Junction Temperature

125

°C

Storage Temperature

-65 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient (Note 1)

75

°C/W

Junction to Case

28

°C/W

JEDEC 51-7 thermal measurement standard

PARAMETER

SYMBOL

RATINGS

UNIT

5 or 3.3±5%

V

2.5~1.5±3%

V

1.25~0.75±3%

V

Junction Temperature

-40~+125

°C

Notes: 1. All voltage values are with respect to the network ground terminal unless otherwise noted.

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

INPUT CURRENT

1

2.5

mA

Standby Current

50

90

μA

OUTPUT VOLTAGE (DDR/DDR II/DDR III)

-20

20

mV

Load Regulation

-20

20

mV

PROTECTION

Current Limit

2.2

A

Thermal Shutdown Temperature

125

170

°C

Thermal Shutdown Hysteresis

35

°C

Shutdown Threshold

Enable

0.6

V

Shutdown

0.2

V
