CD4014BL-S16-R 데이터시트(PDF) 7 Page - Unisonic Technologies |
|
|
|||||||||||||||||||||||||||||
CD4014BL-S16-R 데이터시트(HTML) 7 Page - Unisonic Technologies |
|
|
7 / 9 page  CD4014B Preliminary CMOS IC UNISONICTECHNOLOGIESCO.,LTD 7 of 9 www.unisonic.com.tw QW-R502-606.a TEST CIRCUITS AND WAVEFORMS Test S1 tPLH/tPHL GND Inputs VIN tr, tf VM VLOAD CL RL VCC 20 ns VCC/2 VCC 50 pF 200 KΩ VCC 0V Input 10% 90% tR 10% 90% tF Fig 2. Voltage Waveforms Input Rise and Fall Times VM VIN 0V VOH VOL Fig 3. Voltage Waveforms Propagation Delay and Output Transition Times Input Output tPLH tPHL tPLH tPHL Output 10% 90% 10% 90% 10% 90% tF 10% 90% tR VOH VOL VM VM VM tR tF VM VM Notes: 1. CL includes probe and jig capacitance. 2. All input pulses are supplied by generators having the following characteristics: PRR ≤1MHz, ZO = 50Ω. |
|
|
