CD4081BL-S14-R 데이터시트(PDF) 4 Page - Unisonic Technologies

부품명 CD4081BL-S14-R
상세설명  QUAD 2-INPUT AND BUFFERED B SERIES GATE
PDF  5 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
제조업체  UTC [Unisonic Technologies]
홈페이지  http://www.utc-ic.com
Logo UTC - Unisonic Technologies

CD4081BL-S14-R 데이터시트(HTML) 4 Page - Unisonic Technologies

  CD4081BL-S14-R Datasheet HTML 1Page - Unisonic Technologies CD4081BL-S14-R Datasheet HTML 2Page - Unisonic Technologies CD4081BL-S14-R Datasheet HTML 3Page - Unisonic Technologies CD4081BL-S14-R Datasheet HTML 4Page - Unisonic Technologies CD4081BL-S14-R Datasheet HTML 5Page - Unisonic Technologies
Zoom Inzoom in Zoom Outzoom out
 4 / 5 page
background image
CD4081B
Preliminary
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
4 of 5
www.unisonic.com.tw
QW-R502-569.a
SWITCHING CHARACTERISTICS(TA=25°С, Input: tR=tF=20ns,unless otherwise specified )
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
VDD=5.0V, CL=50pF, RL=200kΩ
120
250
VDD=10V, CL=50pF, RL=200kΩ
50
100
tPLH
VDD=15V, CL=50pF, RL=200kΩ
35
70
VDD=5.0V, CL=50pF, RL=200kΩ
100
250
VDD=10V, CL=50pF, RL=200kΩ
40
100
Propagation delay from
Input(A or B) to Output(Y)
tPHL
VDD=15V, CL=50pF, RL=200kΩ
30
70
ns
VDD=5.0V, CL=50pF, RL=200kΩ
90
200
VDD=10V, CL=50pF, RL=200kΩ
50
100
Transition Time
tTLH
tTHL
VDD=15V, CL=50pF, RL=200kΩ
40
80
ns
OPERATING CHARACTERISTICS(Ta=25°С)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Average Input Capacitance
CIN
Any Input
5
7.5
Power Dissipation Capacitance
CPD
Any Gate
18
pF



Html Pages

1 2 3 4 5


데이터시트 다운로드

Go To PDF Page


링크 URL
