UNISONIC TECHNOLOGIES CO., LTD

UT9564

Preliminary

Power MOSFET

www.unisonic.com.tw

1 of 4

Copyright © 2011 Unisonic Technologies Co., Ltd

QW-R502-390.c

P-CHANNEL ENHANCEMENT

MODE POWER MOSFET

DESCRIPTION

The UTC UT9564 is a P-ch enhancement mode power

MOSFET and it uses UTC perfect technology to provide customers

with fast switching, ruggedized device design, low on-resistance and

cost-effectiveness.

The UTC UT9564 is ideal for applications such as low voltage

applications, DC/DC converters and all commercial-industrial surface

mount applications.

FEATURES

* Simple Drive Requirement

* Fast Switching Speed

* Low On-Resistance

SYMBOL

TO-252

SOP-8

1

ORDERING INFORMATION

Ordering Number

Pin Assignment

Lead Free

Halogen Free

Package

12

3456

7

8

Packing

UT9564L-TN3-R

UT9564G-TN3-R

TO-252

G D

S

-

-

-

-

- Tape Reel

UT9564L-S08-R

UT9564G-S08-R

SOP-8

S

S

S G D D D

D Tape Reel

UT9564L-S08-T

UT9564G-S08-T

SOP-8

S

S

S G D D D

D

Tube
