UNISONIC TECHNOLOGIES CO., LTD

UTD405

Power MOSFET

www.unisonic.com.tw

1 of 5

QW-R502-199.A

P-CHANNEL

ENHANCEMENT MODE

DESCRIPTION

The UTD405 can provide excellent RDS(ON), low gate

charge and low gate resistance by using advanced trench

technology. This device is well suited for high current load

applications with the excellent thermal resistance.

FEATURES

* RDS(ON) = 32mΩ @VGS = -10 V

* Low capacitance

* Low gate charge

* Fast switching capability

* Avalanche energy specified

SYMBOL

1.Gate

3.Source

2.Drain

*Pb-free plating product number: UTD405L

ORDERING INFORMATION

Ordering Number

Pin Assignment

Normal

Lead Free Plating

Package

1

2

3

Packing

UTD405-TN3-R

UTD405L-TN3-R

TO-252

G

D

S

Tape Reel

UTD405-TN3-T

UTD405L-TN3-T

TO-252

G

D

S

Tube
