UNISONIC TECHNOLOGIES CO., LTD

DTC114Y

NPN SILICON TRANSISTOR

www.unisonic.com.tw

1 of 3

Copyright © 2011 Unisonic Technologies Co., Ltd

QW-R223-003,D

NPN DIGITAL TRANSISTOR

(BUILT- IN BIAS RESISTORS)

FEATURES

* Built-in bias resistors that implies easy ON/OFF applications.

* The bias resistors are thin-film resistors with complete isolation to

allow negative input.

EQUIVALENT CIRCUIT

ORDERING INFORMATION

Ordering Number

Package

Pin Assignment

Packing

Lead Free

Halogen Free

1

2

3

DTC114YL-AE3-R

DTC114YG-AE3-R

SOT-23

G

I

O

Tape Reel

DTC114YL-AL3-R

DTC114YG-AL3-R

SOT-323

G

I

O

Tape Reel

DTC114YL-AN3-R

DTC114YG-AN3-R

SOT-523

G

I

O

Tape Reel

DTC114YL-T92-B

DTC114YG-T92-B

TO-92

G

O

I

Tape Box

DTC114YL-T92-K

DTC114YG-T92-K

TO-92

G

O

I

Bulk

DTC114YL-T92-R

DTC114YG-T92-R

TO-92

G

O

I

Tape Reel

DTC114YL-T9S-K

DTC114YG-T9S-K

TO-92SP

G

O

I

Bulk

MARKING
