UTM3023
Power MOSFET
UNISONICTECHNOLOGIESCO.,LTD
3 of 5
www.unisonic.com.tw
QW-R502-178.A
TYPICAL CHARACTERISTICS
VDS=10V
TJ=125℃
TJ=25℃
TJ=-55℃
40
30
20
10
0
1.0
1.5
2.0
2.5
3.0
3.5
4.0
Gate-to-Source Voltage,VGS (V)
Transfer Characteristics
10
8
6
4
2
0
0
5
10
15
20
25
30
Drain-to-Source Voltage,VDS (V)
Output Characteristics
VGS=5,6,7,8,9,10V
4V
VGS=3V
IDS=250μA
VGS=5V
VGS=10V
1.2
1.0
0.8
0.6
0.4
-50 -25
0
25
50
75 100 125 150
Junction Temperature,TJ (℃)
Threshold Voltage vs. Junction
Temperature
05
10
30
25
20
15
Drain Current,IDS (A)
0.000
0.005
0.010
0.015
0.020
0.025
0.030
0.035
0.040
On-Resistance vs. Drain Current
