FDA217

Absolute Maximum Ratings are stress ratings. Stresses in

excess of these ratings can cause permanent damage to

the device. Functional operation of the device at conditions

beyond those indicated in the operational sections of this

data sheet is not implied.

Absolute Maximum Ratings @ 25ºC

Parameter

Ratings

Units

Reverse Input Voltage

5

V

Input Control Current

Peak (10ms)

50

mA

1A

140

mW

500

mW

ESD Rating, Human Body Model

8

kV

Isolation Voltage, Input to Output

3750

V

rms

Operational Temperature

-40 to +85

°C

Storage Temperature

-40 to +125

°C

Parameter

Conditions

Symbol

Min

Typ

Max

Units

Output Characteristics

Open Circuit Voltage

I

V

OC

10.5

11.75

15.3

V

Short Circuit Current

I

I

SC

2.5

4.5

-

A

I

5

9

I

7.5

13.5

I

10

18.5

I

15

27

Switching Speeds

Turn-On

I

t

on

--

2

ms

Turn-Off

t

off

-

-

0.5

Offstate Resistance

V

R

100

770

3300



Input Characteristics

LED Current to Activate

I

-

3.8

5

mA

Input Voltage Drop

I

V

F

0.9

1.26

1.4

V

Reverse Input Current

V

I

R

-

-

10

µA

Common Characteristics

Capacitance, Input to Output

-

-

-

3

-

pF

Electrical Characteristics @ 25ºC
