31-203-RFX datasheet(6/30 Pages) AMPHENOL

6 / 30 page

BNC 50 ohm

Amphenol

Bulkhead Jacks

110

Amphenol Corporation Tel: 800-627-7100

www.amphenolrf.com

Fig. 1

31-30220-1

31-30220-8

31-4541

31-4541-RFX

31-4542

Ω BNC QUICKTRIM® Plugs

Fig. 2

Fig. 3

BNC SURETWIST® Plugs

31-5136

31-5136-RFX

31-5137

31-5137-RFX

BNC FCP Plugs

31-4700

31-4702

• accommodates cable diameter

* recognized under the component program of U.L., Inc.

v distributor stocked s includes outer ferrule

c•

a s

BNC CABLE PLUGS

Cable

Cable Attachment

Dimensions, inches (millimeters)

Notes

Military

Amphenol

Fig.

RG-/U

Outer

Inner

a s

c •

CAI

Plt.

Ins.

Number

58 B/U

SURETWIST®

1.47(37.3)

.562(14.3)

.181(4.6)

C28

D15

—

31-5137

SURETWIST®

1.48(37.6)

.571(14.5)

.185(4.7)

C28

D23

—

31-5137-RFX

FCP

Pliers

1.06(27.0)

.563(14.3)

.206(5.23)

C30

—

31-4700*

QUICKTRIM®

1.06(27.0)

.563(14.3)

.207(5.3)

C29

—

31-30220-1

QUICKTRIM®

1.03(26.2)

.562(14.3)

.252(6.2)

C29

(IBM 1836444)

31-4541

QUICKTRIM®

1.03(26.2)

.562(14.3)

.252(6.2)

C29

D23

—

31-4541-RFX

SURETWIST®

1.47(37.3)

.562(14.3)

.242(6.1)

C28

D15

—

31-5136

SURETWIST®

1.48(37.6)

.571(14.5)

.242(6.1)

C28

D23

—

31-5136-RFX

FCP

Pliers

1.06(27.0)

.563(14.3)

.259(6.56)

C30

—

31-4702*

223

QUICKTRIM®

1.06(27.0)

.563(14.3)

.225(5.7)

C29

—

31-30220-8

Belden 9268

QUICKTRIM®

1.06(27.0)

.563(14.3)

.275(6.99)

C29

(IBM 1836447)

31-4542
