Data Sheet

ADA4432-1/ADA4433-1

Rev. A | Page 9 of 28

TYPICAL PERFORMANCE CHARACTERISTICS

ADA4432-1 TYPICAL PERFORMANCE CHARACTERISTICS

TA = 25°C, +VS = 3.3 V, RL = 150 Ω, unless otherwise specified.

Figure 7. Frequency Response at Various Output Amplitudes

Figure 8. Large Signal Frequency Response at Various Temperatures

Figure 9. 1 dB Flatness Response at Various Load Resistances

Figure 10. 1 dB Flatness Response at Various Output Amplitudes

Figure 11. 1 dB Flatness Response at Various Temperatures

Figure 12. Group Delay vs. Frequency
