ADP199

Data Sheet

Rev. 0 | Page 8 of 16

TEMPERATURE (°C)

0.01

0.1

–40

–20

20406080

100

0.8V

1.0V

1.2V

1.5V

1.8V

2.2V

2.6V

3.0V

3.3V

3.6V

Figure 16. Output Shutdown Current vs. Temperature,

VOUT = 0 V, Different Input Voltage (VIN)

CH2 500mV

CH1 1V

CH3 20mA Ω

M10µs

A CH1

100mV

T 10%

OUTPUT VOLTAGE

VEN

INPUT CURRENT

Figure 17. Typical Turn-On Time and Inrush Current,

VIN = 1.2 V, 10 mA Load, COUT = 1 μF

CH2 500mV

CH1 1V

CH3 200mA Ω

M10µs

A CH1

100mV

T 10%

OUTPUT VOLTAGE

VEN

INPUT CURRENT

Figure 18. Typical Turn-On Time and Inrush Current,

VIN = 1.2 V, 500 mA Load, COUT = 1 μF

CH2 1V

CH1 1V

CH3 50mA Ω

M10µs

A CH1

100mV

T 10%

OUTPUT VOLTAGE

VEN

INPUT CURRENT

Figure 19. Typical Turn-On Time and Inrush Current,

VIN = 1.8 V, 10 mA Load, COUT = 1 μF

CH2 1V

CH1 1V

CH3 200mA Ω

M10µs

A CH1

100mV

T 10%

OUTPUT VOLTAGE

VEN

INPUT CURRENT

Figure 20. Typical Turn-On Time and Inrush Current,

VIN = 1.8 V, 500 mA Load, COUT = 1 μF

CH2 1V

CH1 2V

CH3 200mA Ω

M4µs

A CH1

1.28mV

T 10%

OUTPUT VOLTAGE

VEN

INPUT CURRENT

Figure 21. Typical Turn-On Time and Inrush Current,

VIN = 3.6 V, 10 mA Load, COUT = 1 μF
