background image
SEMICONDUCTOR
RoHS
RoHS
Nell High Power Products
Page 6 of 6
40FD(R)Series
Fig .10 Typical recovered charge vs.
rate of fall of forward current.
40FD(R), 800 to 1200V
T
=
25
°C
J
T
=
12
5°
C
J
2
10
4
10
5
10
3
10
1
3
10
30
100
Rate of fall of forward current (A/µs)
www.nellsemi.com
10
l = 125A
F
l = 20A
F
l = 1A
F
19(0.75)
1/4” 28UNF-2A
For metric devices: M6×1.0
(0.24/0.26)
Ø15(Ø0.6)
6.1/6.7
Ø4.3(Ø01.7)
(0.03/0.06)
0.9/1.5
DO-203AB (DO-5)
40FD(R)..
40FD..
AII dimensions in millimeters (inches)
