Low Voltage Fuse Links Catalogue

For Product Data Sheets, visit www.cooperbussmann.com

CHD

250 - 400V / 10 - 32A

Sizes: 8x23, 10x25, 8x31

10x31, 10x38

Specifications

Description:

Fuse Holder for domestic cylindrical

fuses. Secured to DIN rail and available with light

indicator for active fuse function. Range as single-pole

and single-pole plus neutral in one module.

Ratings:

Applications:

Protection for power lines, heating

circuits, lighting circuits. electrical domestic appliances

and domestic electricity meters

Agency Information:

NF C 62203, EN IEC 60269-3,

NF marking on all models

Modular Domestic Fuse Holders

Volts: - 250V ac (8x31, 10x25)

- 400V ac (8x31, 10x31, 10x38)

Amps: - 10 - 32A

IR - 6kA (6x23, 8x23, 10x25)

- 20kA (8x31, 10x31, 8x36, 10x38)

Catalogue Numbers

Size

Rating

(A)

Voltage

(V)

Single Pole

Single Pole + Neutral

without

Indicator

with

Indicator

without

Indicator

with

Indicator

8x23

250

CHD8231D CHD8231DI CHD8231DN CHD8231DNI 12

10x25

250

CHD10251D CHD10251DI CHD10251DN CHD10251DNI 12

8x31

400

CHD8311D CHD8311DI CHD8311DN CHD8311DNI 12

10x31

400

CHD10311D CHD10311DI CHD10311DN CHD10311DNI 12

10x38

400

CHD1038D CHD1038DI CHD1038DN CHD1038DNI 12

Neutral

400

CHDND

UP: Unit Packing
