Y-CONC-R422L-RJCU-2000-B datasheet(10/42 Pages) YAMAHA

10 / 42 page

IP20 Protected Components

Description:

IP20 holding frames 1x, 2x or 4x format.

For use with all RJ45 and USB IP20Lock products

IP20 Halterahmen in 1x, 2x oder 4x Ausführung zur Verwendung

mit allen RJ45 und USB IP20Lock Produkten

Specifications: Material PA66 (Black)

Operating Temp.: -20°C ~ +120°C

Betriebstemp.

Description:

IP20 lock strain relief with vibration resistant locking

clips. Also available with additional locking slider for

increased mechanical retention. For use with all Y-Con

plugs

IP20-Zugentlastung mit vibrationsstabilen Rasthaken.

Auch mit zusätzlichem Schiebeverschluss für verbesserte mechanische

Rückhaltekraft verfügbar. Für den Einsatz mit allen Y-Con Kabelsteckern

Material:

PA66

Colour:

Y-ConIP20Lock-10 (Black)

Farbe

Y-ConIP20Lock-20 (Black & White)

Specifications:

Operating Temp.: -20°C ~ +120°C

Betriebstemp.

Part Number

Type

Y-ConIP20Lock-10

Standard

Y-ConIP20Lock-20

With additional locking slider

Part Number

No. of Holding Frames

Y-ConIP20HFR-10

Y-ConIP20HFR-20

Y-ConIP20HFR-40

Series

10 = Standard Type

20 = With Locking Slider

Y-ConIP20Lock - **

Part Number (Details)

Y-ConIP20Lock-10

Y-ConIP20Lock-20

Outline Dimensions:

Series

Number of Holding Frames

Y-ConIP20HFR - *

Part Number (Details)

Y-ConIP20Lock-10

Y-ConIP20Lock-20

TECHNISCHE ÄNDERUNGEN VORBEHALTEN – MASSE IN MILLIMETER
