U74LVC86A

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

3 of 6

www.unisonic.com.tw

QW-R502-783.A

PARAMETER

SYMBOL

TEST CONDITIONS

UNIT

Supply Voltage

-0.5 ~ 6.5

V

Input Voltage

-0.5 ~ 5.5

V

Output Voltage (any output in the high or low state)

V

Input Clamp Current

-50

mA

Output Clamp Current

-50

mA

Output Current

±50

mA

±100

mA

Power Dissipation

500

mW

Storage Temperature

-65 ~ +150

°C

Notes: 1. The input and output voltage ratings may be exceeded if the input and output current ratings are observed.

2. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

THERMAL DATA

PARAMETER

SYMBOL

RATING

UNIT

Junction to Ambient

115

°C/W

RECOMMENDED OPERATING CONDITIONS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

MAX

UNIT

Max. speed performance

2.7

3.6

Supply Voltage

Low-voltage applications

1.2

3.6

V

1.7

High-Level Input Voltage

2.0

V

GND

0.7

Low-Level Input Voltage

0.8

V

Input Voltage

0

5.5

V

Output Voltage

0

V

20

Input Transition Rise or Fall Rate

Δt/Δv

10

ns/V

Operating Temperature

-40

+85

°C
