U74LVC2G02
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
4 of 5
www.unisonic.com.tw
QW-R502-790.A
STATIC CHARACTERISTICS(Cont.)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Quiescent Supply Current
VCC=1.65 to 5.5V,
VIN=VCC or GND, IOUT=0
10
μA
Additional Quiescent Supply
Current Per Input Pin
ΔICC
VCC=3 to 5.5V,
One input at VCC-0.6V,
Other inputs at VCC or GND
500
uA
Input Capacitance
CIN
VCC=3.3V, VIN=VCC or GND
5
pF
DYNAMIC CHARACTERISTICS
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Propagation Delay From
Input (A or B) to Output(Y)
tPHL /tPLH
VCC =1.8V±0.15V, CL =30 pF,
RL=1KΩ
3.2
8.9
ns
VCC=2.5V±0.2V, CL =30 pF, RL=500Ω
1
5.4
VCC=3.3V±0.3V, CL =50 pF, RL=500Ω
1
4.9
VCC=5V±0.5V, CL =50 pF, RL=500Ω
1
4.4
Note: See Fig. 1 and Fig. 2 for test circuit and waveforms.
OPERATING CHARACTERISTICS
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
Cpd Power Dissipation
Capacitance
CPD
VCC=3.3V, f=10MHz
19
