© Coilcraft, Inc. 2011

Specifications subject to change without notice.

Please check our website for latest information.

Document MS578-1 Revised 11/17/11

Imax

±10% (µH)

(MHz)

(Ohms)

(A)

(A)

MS413RAM901KSZ

0.9

25

415

0.120

1.4

.076

MS413RAM112KSZ

1.1

24

376

0.130

1.3

0.72

MS413RAM132KSZ

1.3

37

198

0.145

1.2

0.64

MS413RAM152KSZ

1.5

22

135

0.155

1.1

0.62

MS413RAM192KSZ

1.9

29

126

0.180

1.0

0.60

MS413RAM222KSZ

2.2

21

106

0.186

0.95

0.58

MS413RAM272KSZ

2.7

22

70

0.210

0.80

0.57

MS413RAM332KSZ

3.3

21

59

0.240

0.75

0.53

MS413RAM392KSZ

3.9

21

55

0.260

0.70

0.50

MS413RAM472KSZ

4.7

27

48

0.450

0.70

0.36

MS413RAM582KSZ

5.8

21

37

0.320

0.55

0.45

MS413RAM682KSZ

6.8

20

33

0.355

0.50

0.42

MS413RAM822KSZ

8.2

20

34

0.380

0.50

0.42

MS413RAM103KSZ

10.0

22

26

0.540

0.45

0.36

■

Ferrite construction provides lowest DCR and highest current

rating of our 1008 size inductors.

■

Available in 14 inductance values from 0.9 to 10 µH, all at

10% tolerance.

Core material Ferrite

Terminations Tin-lead (63/37) over silver-platinum-glass frit

Ambient temperature –55°C to +125°C with Imax current, +125°C

to +155°C with derated current

Storage temperature Component: –55°C to +155°C.

Tape and reel packaging: –55°C to +80°C

Resistance to soldering heat Max three 40 second reflows at

+260°C, parts cooled to room temperature between cycles

Temperature Coefficient of Inductance (TCL) +100 to +350 ppm/°C

Moisture Sensitivity Level (MSL) 1 (unlimited floor life at <30°C /

85% relative humidity)

Enhanced crush-resistant packaging 2000 per 7

″ reel

Plastic tape: 8 mm wide, 0.3 mm thick, 4 mm pocket spacing,

2.0 mm pocket depth

1. When ordering, please specify

testing code:

MS413RAM103KSZ

Testing: Z = COTS

H = Screening per Coilcraft CP-SA-10001

N = Screening per Coilcraft CP-SA-10003

2. Inductance measured at 2.5 MHz using Coilcraft SMD-A fixture in an

Agilent/HP 4286A impedance analyzer or equivalent with Coilcraft-

provided correlation pieces.

3. Q measured at 2.5 MHz using an Agilent/HP 4291A with an Agilent/HP

16197 test fixture or equivalents.

4. SRF measured using an Agilent/HP 8753ES network analyzer or

equivalent with a Coilcraft SMD-D fixture.

5. DCR measured on a Keithley 580 micro-ohmmeter or equivalent and a

Coilcraft CCF858 test fixture.

6. DC current at which the inductance drops 10% (typ.) from its value

without current.

7. Electrical specifications at 25°C.

Refer to Doc 362 “Soldering Surface Mount Components” before soldering.

This robust version of Coilcraft’s standard 1008AF series

features high temperature materials that allow opera-

tion in ambient temperatures up to 155°C. The tin-lead

(Sn-Pb) terminations ensure the best possible board

adhesion.

1008 CHIP INDUCTORS
