1 / 8 page

ET4N60

www.estek.com.cn

Copyright @ Estek Electronics Co., Ltd

Version 0.2

26 Sep 2011

1

600V, 4A, N-Channel Power MOSFET

Features

Symbol

Applications

Pin Description

Ordering Information

Pin Assignment

Part Number

Package

1

2

3

Packing

ET4N60-220-T

TO-220

G

D

S

Tube

ET4N60-220F-T

TO-220F

G

D

S

Tube

ET4N60-252-T

TO-252

G

D

S

Tube

ET4N60-252-R

TO-252

G

D

S

Tape Reel

Switching Application

Adaptor

LED Lighting

RDS(ON)= (Max. 2.5 Ω)@VGS=10V.

Gate Charge (Typical 15nC).

Improved dv/dt Capability,

High Ruggedness.

100% Avalanche Tested.

Maximum Junction Temperature

Range(150oC).

VDSS=600V

IDS=4A

RDS(ON)=2.5 Ω
