MSAU300 SERIES

DC/DC CONVERTER 1W, SMD-Package, High Isolation

E-mail:sales@minmax.com.tw

Tel:886-6-2923150

2011/08/11 REV:6

Page 3 of 4

Package Specifications

Mechanical Dimensions

Connecting Pin Patterns

►All dimensions in mm (inches)

►Tolerance: X.X±0.25 (X.XX±0.01)

X.XX±0.13 ( X.XXX±0.005)

►Pins ±0.05 (±0.002)

Pin Connections

Physical Characteristics

Single Output

Dual Output

Case Size

15.3x8.0x6.75mm (0.60x0.31x0.27 Inches)

-Vin

+Vin

Case Material

Molding (flammability to UL 94V-0 rated)

-Vout

Common

Weight

2.2g

-Vout

+Vout

NA : Not Available for Electrical Connection

15.3 [0.6]

0.60 [0.02]

12 11 10

1.3

2.54

[0.1]

5.08

[0.2]

[0.05]

9.2 [0.36]

7.0 [0.28]

[0.2]

5.08

S SEATING PLANE

0.15 S

( Magnification of A )

1.7 [0.07]

12.7 [0.50]

10.8 [0.43]

5.08 [0.20]

1.0 [0.04]

2.54 [0.10]
