Data Sheet
ADL5906
Rev. 0 | Page 9 of 32
TYPICAL PERFORMANCE CHARACTERISTICS
VPOS1 = VPOS2 = 5 V, single-ended input drive, VRMS connected to VSET, VTGT = 0.8 V, CRMS = 0.1 µF, TA = +25°C (green),
−55°C (light blue), −40°C (blue), +85°C (red), +105°C (orange), and +125°C (black), where appropriate. Error referred to slope
and intercept at indicated calibration points. Input RF signal is a sine wave (CW), unless otherwise indicated.
0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
–65 –60 –55 –50 –45 –40 –35 –30 –25 –20 –15 –10 –5
0
5
10
100MHz TO 1GHz
20MHz
10MHz
PIN (dBm)
2GHz
3GHz
4GHz
5GHz
6GHz
7GHz
8GHz
9GHz
10GHz
Figure 3. Typical VRMS vs. Input Power (dBm) vs. Frequency
(10 MHz to 10 GHz) at 25°C
–6
–5
–4
–3
–2
–1
0
1
2
3
4
5
6
0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
–65
–55
–45
–35
–25
–15
–5
5
PIN (dBm)
CW
QPSK PEP = 3.8dB
16 QAM PEP = 6.3dB
64 QAM PEP = 7.4dB
Figure 4. Error from CW Linear Reference vs. Signal Modulation
(QPSK, 16 QAM, 64 QAM), Frequency = 900 MHz, CRMS = 0.1 µF,
Three Point Calibration at 0 dBm, −40 dBm, and −55 dBm
–6
–5
–4
–3
–2
–1
0
1
2
3
4
5
6
0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
–65
–55
–45
–35
–25
–15
–5
5
PIN (dBm)
CW
CDMA 2000 PEP = 11.02dB
1C W-CDMA PEP = 10.56dB
4C W-CDMA PEP = 12.08dB
Figure 5. Error from CW Linear Reference vs. Signal Modulation (CDMA 2000,
One-Carrier W-CDMA, Four-Carrier W-CDMA), Frequency = 2.14 GHz,
CRMS = 0.1 µF, Three Point Calibration at 0 dBm, −40 dBm, and −55 dBm
–20dBm
0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
0.01
0.1
1
10
FREQUENCY (GHz)
–50dBm
–10dBm
0dBm
–30dBm
–40dBm
Figure 6. Typical VRMS vs. Frequency for Six RF Input Levels
–6
–5
–4
–3
–2
–1
0
1
2
3
4
5
6
0
0.5
1.0
1.5
2
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
–65
–55
–45
–35
–25
–15
–5
5
PIN (dBm)
CW
QPSK PEP = 3.8dB
16 QAM PEP = 6.3dB
64 QAM PEP = 7.4dB
Figure 7. Error from CW Linear Reference vs. Signal Modulation
(QPSK, 16 QAM, 64 QAM), Frequency = 2.14 GHz, CRMS = 0.1 µF,
Three Point Calibration at 0 dBm, −40 dBm, and −55 dBm
–6
–5
–4
–3
–2
–1
0
1
2
3
4
5
6
0
0.5
1.0
1.5
2
2.5
3.0
3.5
4.0
4.5
5.0
5.5
6.0
–65
–55
–45
–35
–25
–15
–5
5
PIN (dBm)
CW
LTE TM1 1CR 20MHz PEP = 11.58dB
Figure 8. Error from CW Linear Reference vs. Signal Modulation
(LTE TM1 One-Carrier, 20 MHz), Frequency = 2.14 GHz, CRMS = 0.1 µF,
Three Point Calibration at 0 dBm, −40 dBm, and −55 dBm
