03/08

Please read Cautions and warnings and

Important notes at the end of this document.

Size 0603 (EIA) and/or 1608 (IEC)

Rated inductance 1 nH to 220 nH

Rated current 110 mA to 1800 mA

Construction

■ Copper-plated ceramic core

■ Laser-cut winding, epoxy-coated

Features

■ Temperature range up to 150 °C

■ High resonance frequency

■ Close inductance tolerance

■ Free of polarization effect

■ High mechanical stability

■ Qualified to AEC-Q200

■ Suitable for lead-free reflow soldering

as referenced in JEDEC J-STD 020C

■ RoHS-compatible

Applications

Resonant circuits, impedance matching for

■ Multimedia

■ Car access systems

■ Wireless communication systems

■ TPMS (Tire Pressure Monitoring System)

■ GPS (Global Positioning System)

■ Digital cameras

Terminals

■ Base material Al2O3 ceramic with Cu layer

■ Layer composition Ni, Sn (lead-free)

■ Electro-plated

Marking

■ No marking on component

■ Minimum data on reel:

Manufacturer, ordering code, L value,

quantity, date of packing

Delivery mode and packing unit

■ 8-mm cardboard tape, wound on 180-mm ∅ reel

■ Bulk case on request

■ Packing unit: 4000 pcs./reel

B82496C

SMT inductors, SIMID series

SIMID 0603-C
