ADP5052ACPZ-R7 데이터시트(PDF) 37 Page - Analog Devices |
|
|
|||||||||||||||||||||||||||||
ADP5052ACPZ-R7 데이터시트(HTML) 37 Page - Analog Devices |
|
37 / 40 page ![]() Data Sheet ADP5052 Rev. 0 | Page 37 of 40 FACTORY DEFAULT OPTIONS Table 27 lists the factory default options programmed into the ADP5052 when the device is ordered (see the Ordering Guide). To order the device with options other than the default options, contact your local Analog Devices sales or distribution representative. Table 15 through Table 26 list all available options for the device. Table 27. Factory Default Options Option Default Value Channel 1 output voltage 0.8 V adjustable output Channel 2 output voltage 0.8 V adjustable output Channel 3 output voltage 0.8 V adjustable output Channel 4 output voltage 0.8 V adjustable output PWRGD pin (Pin 20) output Monitor Channel 1 output Output discharge function Enabled for all four buck regulators Switching frequency on Channel 1 1 × switching frequency set by the RT pin Switching frequency on Channel 3 1 × switching frequency set by the RT pin SYNC/MODE pin (Pin 43) function Forced PWM/automatic PWM/PSM mode setting with the ability to synchronize to an external clock Hiccup protection Enabled for overcurrent events Short-circuit latch-off function Disabled for output short-circuit events Overvoltage latch-off function Disabled for output overvoltage events |
|
