Performance

Data

1MD06-059-10

Performance

Data

1MD06-059-12

Thermoelectric Cooling Solutions

@ 27ºC, Vacuum

ΔTmax

K

Qmax

W

Imax

A

Umax

V

1MD06-059-10

72

7.33

1.6

7.4

@50ºC, N2

ΔTmax

K

Qmax

W

Imax

A

Umax

V

1MD06-059-10

77

7.98

1.6

8.1

Note: Performance data is specified for optimal optimal conditions (TEC hot side is stabilized at ambient temperature).

Heatsink thermal resistance is not included into estimations. Use TECCad Software for estimations under different conditions.

@ 27ºC, Vacuum

ΔTmax

K

Qmax

W

Imax

A

Umax

V

1MD06-059-12

72

6.20

1.4

7.4

@50ºC, N2

ΔTmax

K

Qmax

W

Imax

A

Umax

V

1MD06-059-12

77

6.74

1.4

8.1

Note: Performance data is specified for optimal optimal conditions (TEC hot side is stabilized at ambient temperature).

Heatsink thermal resistance is not included into estimations. Use TECCad Software for estimations under different conditions.
