INTEGRATED CIRCUITS DIVISION

CPC1593

www.ixysic.com

R01

MECHANICAL DIMENSIONS

CPC1593G

CPC1593GS

Dimensions

(inches)

PCB Land Pattern

0.254 ± 0.0127

(0.010 ± 0.0005)

7.620 ± 0.254

(0.300 ± 0.010)

0.635 ± 0.127

(0.025 ± 0.005)

3.302 ± 0.051

(0.130 ± 0.002)

4.445 ± 0.254

(0.175 ± 0.010)

2.54

(0.10)

8.90

(0.3503)

1.65

(0.0649)

0.65

(0.0255)

8.382 ± 0.381

(0.330 ± 0.015)

2.54 ± 0.127

(0.100 ± 0.005)

9.524 ± 0.508

(0.375 ± 0.020)

6.350 ± 0.127

(0.250 ± 0.005)

0.457 ± 0.076

(0.018 ± 0.003)

1.651 ± 0.254

(0.065 ± 0.010)

1.651 ± 0.254

(0.065 ± 0.010)

Pin 1

Dimensions

(inches)

PCB Hole Pattern

6.350 ± 0.127

(0.250 ± 0.005)

2.540 ± 0.127

(0.100 ± 0.005)

7.620 ± 0.127

(0.300 ± 0.005)

5.080 ± 0.127

(0.200 ± 0.005)

6 - 0.800 DIA.

(6 - 0.031 DIA.)

0.254 ± 0.0127

(0.010 ± 0.0005)

9.144 ± 0.508

(0.360 ± 0.020)

7.239 TYP

(0.285 TYP)

7.620 ± 0.254

(0.300 ± 0.010)

3.302 ± 0.051

(0.130 ± 0.002)

4.064 TYP

(0.160 TYP)

0.457 ± 0.076

(0.018 ± 0.003)

8.382 ± 0.381

(0.330 ± 0.015)

2.54 ± 0.127

(0.100 ± 0.005)

6.350 ± 0.127

(0.250 ± 0.005)

1.651 ± 0.254

(0.065 ± 0.010)

Pin 1
