PACKAGING INFORMATION

5.1

Package Marking Information

Package marking information not available at this time.

5.2

Taping Forms

Component Taping Orientation for 16-Pin SOIC (Wide) Devices

W

PIN 1

User Direction of Feed

Standard Reel Component Orientation

for TR Suffix Device

P

Package

Carrier Width (W)

Pitch (P)

Part Per Full Reel

Reel Size

16-Pin SOIC (W)

16 mm

12 mm

1000

13 in

Carrier Tape, Number of Components Per Reel and Reel Size
