background image
AD8236
Rev. 0 | Page 9 of 20
TYPICAL PERFORMANCE CHARACTERISTICS
G = 5, +VS = 5 V, VREF = 2.5 V, RL = 100 kΩ tied to GND, TA = 25°C, unless otherwise noted.
0
CMRR (µV/V)
700
600
500
400
300
200
100
–40
–20
0
20
40
Figure 5. Typical Distribution of CMRR, G = 5
0
VOSI (µV)
800
600
400
200
–4000 –3000 –2000 –1000
0
1000
3000
2000
4000
Figure 6. Typical Distribution of Input Offset Voltage
10
100
1k
1
10
100
1k
10k
FREQUENCY (Hz)
GAIN = 5
GAIN = 200
BANDWIDTH
LIMITED
Figure 7. Voltage Noise Spectral Density vs. Frequency
1s/DIV
5µV/DIV
GAIN = 5
Figure 8. 0.1 Hz to 10 Hz RTI Voltage Noise
1s/DIV
5µV/DIV
GAIN = 200
Figure 9. 0.1 Hz to 10 Hz RTI Voltage Noise
0
20
40
60
80
100
120
140
0.1
1
10
100
1k
10k
100k
FREQUNCY (Hz)
INTERNAL
CLIPPING
GAIN = 100
GAIN = 200
GAIN = 5
GAIN = 10
Figure 10. Positive PSRR vs. Frequency, RTI,
VS = ±0.9 V, ±2.5 V, VREF = 0 V
