RNF/RNMF Series
General Purpose Metal Film Resistor
Stackpole Electronics, Inc.
Resistive Product Solutions
Biased Humidity
MIL-STD 202, Method 103
± 1.5%
Resistance to Solder Heat
MIL-STD 202, Method 210
± 0.5%
Insulation Resistance
JIS C 5202 5.6
± 0.5%
Load Life
MIL-STD 202, Method 108
± 1%
Terminal Strength
MIL-STD 202, Method 211
± 0.2%
Temperature Cycling
JESD22 Method JA-104
± 1%
Moisture Resistance
MIL-STD 202, Method 106
± 0.5%
Operating Temperature Range: -55ºC to +155ºC
Standard / Method
Test
Requirement
0
100
-55ºC
70ºC
80
60
40
20
155ºC
-60
-40
-20
0
20
40
60
80
100
Ambient Temperature (ºC)
120
140
160
180
0.130 ± 0.012
0.071 ± 0.012
1.102 ± 0.118
0.018 ± 0.003
inches
3.30 ± 0.30
1.80 ± 0.30
28.00 ± 3.00
0.45 ± 0.07
mm
0.250 ± 0.026
0.093 ± 0.010
1.102 ± 0.118
0.022 ± 0.003
inches
6.35 ± 0.65
2.35 ± 0.25
28.00 ± 3.00
0.56 ± 0.08
mm
0.344 ± 0.030
0.108 ± 0.039
1.102 ± 0.197
0.026 ± 0.004
inches
8.75 ± 0.75
2.75 ± 1.00
28.00 ± 5.00
0.65 ± 0.10
mm
0.433 ± 0.039
0.177 ± 0.020
1.181 ± 0.118
0.030 ± 0.002
inches
11.00 ± 1.00
4.50 ± 0.50
30.00 ± 3.00
0.75 ± 0.05
mm
0.591 ± 0.039
0.197 ± 0.020
1.339 ± 0.157
0.028 ± 0.004
inches
15.00 ± 1.00
5.00 ± 0.50
34.00 ± 4.00
0.70 ± 0.10
mm
0.130 ± 0.012
0.070 ± 0.003
1.102 ± 0.118
0.017 ± 0.002
inches
3.30 ± 0.30
1.78 ± 0.08
28.00 ± 3.00
0.44 ± 0.05
mm
0.250 ± 0.026
0.093 ± 0.010
1.102 ± 0.118
0.022 ± 0.003
inches
6.35 ± 0.65
2.35 ± 0.25
28.00 ± 3.00
0.56 ± 0.08
mm
RNF14
RNF12
Type / Code
Unit
RNF18
A
B
C
D
Body Length
RNF1
RNMF14
RNMF12
RNF2
Body Diameter
Lead Length (Bulk)
Lead Diameter
Power Derating Curve:
Mechanical Specifications
Performance Characteristics
