Data Sheet

AD5625R/AD5645R/AD5665R, AD5625/AD5665

Rev. C | Page 33 of 36

OUTLINE DIMENSIONS

Figure 75. 10-Lead Lead Frame Chip Scale Package [LFCSP_WD]

3 mm × 3 mm Body, Very Very Thin, Dual Lead

(CP-10-9)

Dimensions shown in millimeters

Figure 76. 14-Lead Thin Shrink Small Outline Package [TSSOP]

(RU-14)

Dimensions shown in millimeters

2.48

2.38

2.23

0.50

0.40

0.30

0.25

0.20

PIN 1 INDEX

AREA

SEATING

PLANE

0.80

0.75

0.70

1.74

1.64

1.49

0.20 REF

0.05 MAX

0.02 NOM

0.50 BSC

EXPOSED

PAD

3.10

3.00 SQ

2.90

PIN 1

INDICATOR

(R 0.15)

FOR PROPER CONNECTION OF

THE EXPOSED PAD, REFER TO

THE PIN CONFIGURATION AND

FUNCTION DESCRIPTIONS

SECTION OF THIS DATA SHEET.

COPLANARITY

0.08

TOP VIEW

BOTTOM VIEW

0.20 MIN

COMPLIANT TO JEDEC STANDARDS MO-153-AB-1

8°

0°

4.50

4.40

4.30

6.40

BSC

PIN 1

5.10

5.00

4.90

0.65 BSC

0.15

0.05

0.30

0.19

1.20

MAX

1.05

1.00

0.80

0.20

0.09

0.75

0.60

0.45

COPLANARITY

0.10

SEATING

PLANE
