21 / 56 page  AD8331/AD8332/AD8334 Rev. G | Page 21 of 56 18nF 22pF IN OUT NETWORK ANALYZER 28Ω 237Ω 28Ω 1:1 50Ω 50Ω 0.1µF OR 1µF 237Ω 10kΩ VGA FB* 120nH *FERRITE BEAD LMD 0.1µF LNA 0.1µF OR 1µF INH 0.1µF OR 1µF 0.1µF 0.1µF Figure 58. Test Circuit—Group Delay vs. Frequency for Two Values of AC Coupling 18nF 22pF 28Ω 237Ω 28Ω 0.1µF 237Ω 50Ω 1:1 OUT NETWORK ANALYZER 50Ω 270Ω FB* 120nH *FERRITE BEAD LMD 0.1µF DUT 0.1µF 0.1µF INH Figure 59. Test Circuit—LNA Input Impedance vs. Frequency in Standard and Smith Chart (S11) Formats 22pF 28Ω 237Ω 28Ω 1:1 0.1µF 0.1µF 237Ω IN OUT NETWORK ANALYZER 50Ω 50Ω VGA LNA FB* 120nH *FERRITE BEAD LMD 0.1µF 0.1µF INH 0.1µF 0.1µF 0.1µF Figure 60. Test Circuit—Frequency Response for Unterminated LNA, Single-Ended 18nF 22pF 28Ω 237Ω 28Ω 0.1µF INH 237Ω 1:1 IN NETWORK ANALYZER 50Ω 270Ω FB* 120nH *FERRITE BEAD LMD 0.1µF DUT 0.1µF 0.1µF Figure 61. Test Circuit—Short-Circuit, Input-Referred Noise |
|
