ADA4700-1

Preliminary Technical Data

Rev. PrB | Page 2 of 10

TABLE OF CONTENTS

Features .............................................................................................. 1

Applications....................................................................................... 1

Pin Configuration............................................................................. 1

General Description ......................................................................... 1

Revision History .......................... Error! Bookmark not defined.

Specifications..................................................................................... 3

VSY = ±50 V Electrical Characteristics....................................... 3

VSY = ±24 V Electrical Characteristics....................................... 5

VSY = ±5 V Electrical Charateristics........................................... 7

Absolute Maximum Ratings ............................................................8

Maximum Power Dissipation ......................................................8

Thermal Resistance .......................................................................8

ESD Caution...................................................................................8

Pin Configuration and Function Description ...............................9

Outline Dimensions ....................................................................... 10

Ordering Guide .......................................................................... 10
