7 / 28 page ![]() AD8555 Rev. A | Page 7 of 28 ABSOLUTE MAXIMUM RATINGS Table 3. Parameter Rating Supply Voltage 6 V Input Voltage VSS − 0.3 V to VDD + 0.3 V Differential Input Voltage1 ±5.0 V Output Short-Circuit Duration to VSS or VDD Indefinite Storage Temperature Range −65°C to +150°C Operating Temperature Range −40°C to +125°C Junction Temperature Range −65°C to +150°C Lead Temperature Range (Soldering, 10 sec) 300°C Table 4. Package Type θJA2 θJC Unit 8-Lead SOIC (R) 158 43 °C/W 16-Lead LFCSP (CP) 44 31.5 °C/W 1 Differential input voltage is limited to ±5.0 V or ± the supply voltage, whi- chever is less. 2 θJA is specified for the worst-case conditions, i.e., θJA is specified for device soldered in circuit board for SOIC and LFCSP packages. |
|
|
