ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltage

±18 V or +36 V

Input Voltage

±V supply

Differential Input Voltage

±V supply

Output Short Circuit to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Lead Temperature (Soldering 60 sec)

300°C

Junction Temperature

150°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

Table 3. Thermal Resistance

Package Type

Unit

8-Lead SOIC_N (R-8)

158

43

°C/W

8-Lead MSOP (RM-8)

210

45

°C/W

14-Lead SOIC_N (R-14)

120

36

°C/W

14-Lead TSSOP (RU-14)

180

35

°C/W

POWER SEQUENCING

The op amp supplies must be established simultaneously with,

or before, the application of any input signals.

If this is not possible, the input current must be limited to 10 mA.
