1 / 6 page

E3B2

2

Method of detection

Retroreflective

Diffuse reflective

Long-range diffuse

Light source

Polarized IR

Non-polarized IR

Sensing distance

5 m (16.40 ft)

7 m (22.97 ft)

2 m (6.56 ft)

3 m (9.84 ft)

Part

Without timers

E3B2-R5M4-US

E3B2-R7M4-US

E3B2-D2M4-US

E3B2-D2M4-US-N

number

ON- and OFF-

(0.5 to 20 s)

E3B2-R5M4D-US

E3B2-R7M4D-US

E3B2-D2M4D-US

—

delay timers

(0.05 to 5 s)

E3B2-R5M4D-US-3

—

E3B2-D2M4D-US-3

E3B2-D2M4-US-N-3

Plug-in Base, Long Range Sensor

E3B2

Plug-in Terminal for Easy

Maintenance and Installation

I Universal AC/DC supply voltage

I Replace sensing head without rewiring

I Detect shiny objects with polarized

retroreflective type

I Long-range diffuse reflective sensors

detect dark objects at long distances

I Built-in ON- and OFF-delay timers

available

I Switch selectable light-on/dark-on

operation

I Mutual interference protection

I Ready-to-use: includes 3 A relay,

mounting bracket and reflector for

retroreflective types

Ordering Information

I SENSORS

I REPLACEMENT PARTS

Description

Part number

Reflector (supplied with retroreflective sensor)

E39-R2

Mounting bracket (supplied with each sensor)

E39-L35
