E3S

14

13

17.8

10.5

1.8

1.2

17.9

(16.7)

E39-S2

*Spacer

Slit (Order Separately)

E39-S2

Note 1. Three sets of slits are provided:

6.5 x 0.5 mm, 6.5 x 1 mm and 6.5 x

2 mm

2. One set consists of two slits, one

each for the Emitter and Receiver.

Slit

E39-S2

Applicable

Sensors

E3S-2E4

E3S-2E41

20

8.3

2.1

22.4

1.2

23.4

(22.2)

E39-S2

*Spacer

E39-S1

Note 1. Four sets of slits are provided:

11 x 0.5 mm, 11 x 1 mm, 11 x 2 mm,

and 11 x 4 mm

2. One set consists of two slits, one

each for the Emitter and Receiver.

Slit

E39-S1

Applicable

Sensors

E3S-5E4

E3S-5E41

Note: The dimensions in parentheses are for when the Spacer is not used.

* With the E3S-2E4 (41), use the Spacer as shown in the figure above so that the supporter

and Mounting Bracket will not be struck when the optical axis is adjusted.

With the E3S-5E4 (41), the Spacer is not particularly required. Use the Spacer, however, to directly mount both the E3S-2E4 (41) and -5E4 (41).

In the interest of product improvement, specifications are subject to change without notice.
