CSM_EE-SY671_672_DS_E_3_1

Reflective Photomicrosensor with Sensitivity Adjuster (Non-modulated)

EE-SY671/672

Photomicrosensor with sensitivity

adjuster.

• Easy adjustment with a built-in sensitivity adjuster.

• Easy optical axis monitoring with a bright light indicator.

• Compact design incorporating a built-in amplifier and special IC

enables direct switching capacity of up to

100 mA.

• Wide operating voltage range: 5 to 24 VDC

• Connection possible with a range of ICs, relays, and Programmable

Controllers (PLCs).

Be sure to read Safety Precautions on

page 4.

Ordering Information

Sensors

* The Dark-ON/Light-ON (selectable) models are normally used as dark-ON models. To use them as light-ON models, short-circuit the L terminal and positive (+)

terminal.

An EE-1001-1 Connector with the terminals already short-circuited is also available.

Accessories (Order Separately)

* Refer to Accessories for details.

Appearance

Sensing method

Sensing distance

Output type

Output

configuration

Model

Horizontal

type

Reflective type

NPN output

Dark-ON or Light-ON

EE-SY671

Vertical type

EE-SY672

Infrared light

1 to 5 mm

Type

Cable length

Model

Remarks

Connector

EE-1001

EE-1001-1

L terminal and positive (+) terminal are already

short-circuited.

EE-1009

Connector with Cable

1 m

EE-1006

EE-1010

2 m

EE-1006

EE-1010

Connector with Robot Cable

1 m

EE-1010-R

2 m

EE-1010-R
