Si3226/7
Si3208/9
32
Preliminary Rev. 0.33
35
NC
No Connect.
36
AGND
I
Analog Ground.
37
IC
Internal connection; leave to float.
38
IC
Internal connection; leave to float.
39
VBAT_1
I
Operating Battery Voltage Channel 1 Input.
40
IC
Internal connection; leave to float.
epad
Exposed Die Attach Paddle.
For adequate thermal management, the exposed die paddle
should be soldered to a printed circuit board pad that is connected
to an electrically-isolated low-impedance inner layer and/or back-
side thermal plane(s) using multiple thermal vias. Do not connect
this pad to ground.
Table 18. Si3208/9 Pin Descriptions (Continued)
QFN Pin #
Symbol
I/O
Description
