Ceramic Discriminators Notice

c CDBLB Series Notice (Handling)

Continued from the preceding page.

P05E.pdf

Nov.24,2011

71

• This catalog has only typical specifications because there is no space for detailed specifications. Therefore, please review our product specifications or consult the approval sheet for product specifications before ordering.

1. Do not use this product with bend. The component

may be damaged if excess mechanical stress is

applied to it mounted on the printed circuit board.

2. The component will be damaged when an excessive

stress is applied.

3. No type of reflow soldering should be applied to this

component.

4. Do not clean or wash the component as it is not

hermetically sealed.

5. Do not use strong acidity flux, more than 0.2wt%

chlorine content, in flow soldering.

6. In case of covering discriminator with over coating,

conditions such as material of resin, cure

temperature, and so on should be evaluated

carefully.
