ATCA-R6270 데이터시트(PDF) 1 Page - List of Unclassifed Manufacturers |
|
|
|||||||||||||||||||||||||||||
ATCA-R6270 데이터시트(HTML) 1 Page - List of Unclassifed Manufacturers |
|
|
1 / 2 page  http://www.adlinktech.com/AdvancedTCA/ 1 1-11 Specifications CPU / Chipset / Memory CPU & FSB Two Intel® Xeon® E5-2648L (8C/16T) (Socket R) Chipset Intel® C604 PCH Memory Eight DDR3-1600 240-pin VLP RDIMM sockets, up to 128 GB BIOS Chip AMI BIOS on SPI flash memory Features Intel® PXE pre-boot Remote Console I/O Interfaces Graphics Silicon Image SM750, PCI-E x1, up to 1920 x 1440 resolution AMC AMC: AMC.0 Midsize, AMC.1 Type4, AMC.2 E2 link to internal GbE controller, AMC.3 S2 Ethernet Dual 10/100/1000BASE-T Base Interface channels Dual 10GBASE-KX4 Fabric Interface channels Dual 10/1001000BASE-T egress ports Storage AMC.3 SATA/SAS ports On-board bootable CFast socket Onboard 2.5 inch HDD mounting space (optional: shares space with AMC bay) USB Three USB 2.0 ports on front panel Front Panel I/O AMC bay, VGA, USB1/2/3, LAN1/2, COM1 PICMG Standards AdvancedTCA PICMG 3.0 R3.0 PICMG 3.1 Ethernet Over PICMG 3.0, Option 9 AdvancedMC PICMG AMC.0: Advanced Mezzanine Card Specification R2.0 PICMG AMC.1: PCI Express and Advanced Switching R1.0 PICMG AMC.2: Gigabit Ethernet R1.0 PICMG AMC.3: Storage Interfaces R1.0 Other Features Operating System Windows Server 2008 R2, Red Hat Enterprise Linux 6 Mechanical and Environmental Form Factor PICMG 3.0 R3.0 AdvancedTCA Dimension 322.25mm x 280mm x 6HP (L x W x H) Weight 3.7KG Operating Temp. 0˚C to 55˚C Storage Temp. -40˚C to 70˚C Humidity 5% to 95%, non-condensing Shock 20G peak-to-peak, 11ms duration, non-operation Vibration Non-operating: 1.88Grms, 5-500Hz each axis Operation: 0.5Grms, 5-500Hz each axis Power Consumption Max 270W Certification FCC, CE, UL, NEBS Level 3 (design) Dual Intel® Xeon® E5-2648L Processor 10 Gigabit Ethernet AdvancedTCA® Processor Blade aTCA-6200A Features Two Intel® Xeon® E5-2648L (8C/16T) processors Eight memory sockets support DDR3-1600 REG/ECC up to 128 GB Intel® C604 PCH Single AMC.0 Mid-size bay Dual 10GBASE-KX4 Fabric Interface channels Intel® Hyper-Threading Technology Intel® QuickPath Interconnect Intel® Ethernet Ordering Information Model Number Description/Configuration aTCA-6200A/D2648L/M64G Dual 8-core Intel® Xeon® E5-2648L 1.8GHz 10GbE processor blade, DDR3 RDIMM 64GB, AMC bay (8GB x8) aTCA-6200A/D2648L/M16G Dual 8-core Intel® Xeon® E5-2648L 1.8GHz 10GbE processor blade, DDR3 RDIMM 16GB, AMC bay (8GB x2) aTCA-6200A/S2648L/M8G Single 8-core Intel® Xeon® E5-2648L 1.8GHz 10GbE processor blade, DDR3 RDIMM 8GB, AMC bay aTCA-R6270 aTCA-R6270 RTM with 1x RJ45 Serial Port, 2x USB 2.0 Port, 2x SFP+ 10GbE Port and 2x SAS/SATA HDD Bay (Hot Swappable) AMC-7000/SATA 320G Mid-size SATA 1.5 Gb/s 320GB AMC HDD module |
