ATCA-R6905 데이터시트(PDF) 2 Page - List of Unclassifed Manufacturers

부품명 ATCA-R6905
상세설명  Dual AMC.0 Mid-size bays
PDF  2 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
제조업체  ETC2 [List of Unclassifed Manufacturers]
홈페이지
Logo ETC2 - List of Unclassifed Manufacturers

ATCA-R6905 데이터시트(HTML) 2 Page - List of Unclassifed Manufacturers

  ATCA-R6905 Datasheet HTML 1Page - List of Unclassifed Manufacturers ATCA-R6905 Datasheet HTML 2Page - List of Unclassifed Manufacturers
Zoom Inzoom in Zoom Outzoom out
 2 / 2 page
background image
Functional Diagram
Bypass
PCI-E x8
Qlogic¨
EP2432
Intel¨
82571EB
PCI-E x1, SATA
DDR2-667 REG/ECC
DDR2-667 REG/ECC
DDR2-667 REG/ECC
DDR2-667 REG/ECC
Intel®
5100 MCH
Intel®
82571EB
Intel®
ICH9R
BIOS
Flash
Flash
Super
I/O
PPS
BMR-H8S
BCM56312
GbE x24
10GbE x2
BIOS
PHY
5464
PHY
5464
LSI®
SAS1064E
ATI®
ES1000
Intel®
Quad/Dual-Core
LV Xeon®
Processor
Intel®
Quad/Dual-Core
LV Xeon®
Processor
AMC.3 SATA
AMC.2 E2/T3
AMC RIO
AMC.1 T4
AMC.2 T3
AMC.2 T3
AMC.2 E2 x2
GbE 1/2
PCI-E x4
PCI-E x4
DMI
SAS
AMC.3 SAS
AMC.2 E2/T3
SAS x2 to RTM
AMC #2
AMC #1
PCI-E x4, SATA x2, USB5/6/7/8
AMC RIO, GbE x2, SAS x2, COM
RGB
USB2/3/4
AMC.3 SATA
PCI 32-bit/33 MHz
PCI 32-bit/33 MHz
USB1
SPI
COM
IPMB 0/1
GbE x2 to RTM
UPD CH
BCH1
BCH2
FCH1
FCH2
10GbE x2
GbE x2
PCI-E x4
DIB-1066/1333M
PCI-E x8
PCI-E x4
PCI-E x4
LPC
SATA x2, USB5/6/7/8
GbE 1/2
COM
* Fabric Riser card
Intel®
82598EB
Mechanical Layout
Two Quad/Dual-Core
Intel® Xeon CPUs
Zone1 – Power / IPMI
AMC.1 PCI-E Type4
AMC.2 GbE E2/Type3
AMC.3 S2 (SATA/SAS)
Server-class
Intel® 5100 chipset
Four DDR2-667
RDIMM sockets
up to 32GB
COM
USB GbE VGA
AMC#2
AMC#1
Hot Swap
Reset
User
Out of Service
Media
Front Panel LED Indicators and Reset
Front Panel I/O Interfaces
