ATCA-R6270 데이터시트(PDF) 1 Page - List of Unclassifed Manufacturers |
|
|
|||||||||||||||||||||||||||||
ATCA-R6270 데이터시트(HTML) 1 Page - List of Unclassifed Manufacturers |
|
|
1 / 1 page  http://www.adlinktech.com/AdvancedTCA/ 1 1-5 aTCA-9300 Specifications CPU / Chipset / Memory CPU Single Quad-Core Intel® Xeon® E3-1275V2 3.5GHZ,8 MB, L2 Cache Single Quad-Core Intel® Xeon® E3-1275V2 3.2GHZ,8MB, L2 cache Single Dual-Core Core™ i3 3.3GHz,3MB L3 cache Chipset Intel® C216 Chipset Memory Four DDR3-1600 240 PIN VLP UDIMM sockets, up to 32 GB BIOS Chip AMIBIOS®8 on SPI flash memory Features Intel® PXE pre-boot I/O Interfaces Graphics Intel® Integrated HD Graphics with DirectX 11 support, up to UXGA 1920 x 1400 resolution AdvancedMC AMC: AMC.0 Mid-size, AMC.1 Type4, AMC.2 E2/Type 3, AMC.3 S2 Ethernet Dual Base Interface channels Dual 10GBASE-KX4/1000BASE-BX Fabric Interface channels Six 10/1001000BASE-T Egress ports Storage AMC.3 SATA 3 Gb/s ports On board bootable CFast socket USB Two USB 2.0 ports Front Panel I/O PICMG Standard AdvancedTCA PICMG® 3.0 R3.0 PICMG® 3.1 Ethernet Over PICMG 3.0 R1.0 , Option1/9 AdvancedMC PICMG® AMC.0: Advanced Mezzanine Card Specification R2.0 PICMG® AMC.1: PCI Express and Advanced Switching R1.0 PICMG® AMC.3: Storage Interfaces R1.0 Other Features Operating System Windows® XP Professional, Windows® Server 2008, Red Hat Enterprise Linux® 6 Mechanical and Environmental Form Factor PICMG® 3.0 R2.0 ECN001 AdvancedTCA® Dimensions 322.25mm x 280mm x 6HP (L x W x H) Weight TBD Operating Temp. 0˚C to 50˚C Storage Temp. -20˚C to 80˚C Humidity 5% to 95%, non-condensing Shock 15G peak-to-peak, 11ms duration, non-operation Vibration Non-operation: 1.88Grms, 5-500Hz each axis Operation: 0.5Grms, 5-500Hz each axis Power Consumption TBD Certifications FCC, CE, UL, NEBS Level 3 (design) Intel® Xeon® E3 Quad-Core 10 Gigabit Ethernet AdvancedTCA® Processor Blade Features Intel® Xeon® E3 Quad-Core or Core™ i3 Dual-Core Uniprocessor DDR3 1600/ECC memory up to 32 GB maximum capacity Intel® C216 chipset Single AMC.0 Mid-size bays Dual 10GBASE-KX4/1000BASE-BX Fabric Interface channels RAID 0/1/5 SATA ports Support Intel® DPDK and Media SDK Ordering Information Model Number Description/Configuration aTCA-9300/S1275V2 Single Quad-Core E3 1275V2 3.5 GHz Xeon® 10GbE processor blade, 8 PCIe lanes to RTM aTCA-9300/S1225V2 Single Quad-core E3 1225V2 3.2GHz Xeon® 10GbE processor blade, 8 PCIe lanes to RTM aTCA-9300/S3220 Single Dual-Core Core i3 3.3GHz 10GbE processor blade, 8 PCIe lanes to RTM aTCA-9300/S1275V2/AMC Single Quad-core E3 1275V2 3.5GHz Xeon® processor blade W/ AMC bay, 12 PCIe lanes to RTM aTCA-9300/S1225V2/AMC Single Quad-core E3 11225V2 3.2GHz Xeon® processor blade W/ AMC bay, 12 PCIe lanes to RTM aTCA-R6270 Rear Transition Module with USB2.0 x2, SFP+ 10GbE port and SATA drive bay x2 (hot swappable) |
