I/O Table

Ordering Information

Model Number

Description/Configuration

Processor Blades

cPCI-3615D/N455/M2G

DDR3-800 soldered memory

cPCI-3615/D525/M2G

DDR3-800 soldered memory

cPCI-3615D/D525/M4G

DDR3-800 soldered memory

cPCI-3615P/N455/M2G

DDR3-800 soldered memory

cPCI-EX3615D/D525/M4G

-40°C to 85°C screened cPCI-3615D/D525/

M4G

cPCI-ET3615D/D525/M2G

-20°C to 70°C screened cPCI-3615D/D525/

M4G

Rear Transition Modules

cPCI-R3610

8HP Rear I/O module for cPCI-3615 with

GbE x2,COM x2, USB x1, SATA x2, VGA,

50mm depth

cPCI-R3610T

8HP Rear I/O module for cPCI-3615 with

GbE x2,COM x2, USB x1, SATA x2, VGA,

80mm depth

(1) Switchable to front or rear by software selection.

Contact your ADLINK representative for different CPU, memory combinations.

cPCI-R3610T

GbE

USB 2.0

COM

VGA

PS/2

KB/MS

SATA

CF

Line-in

Line-out

PMC/

XMC

SBC

cPCI-3615

Faceplate

2

2

1

Onboard

1

cPCI-3615D

Faceplate

2

4

1

1

1

1

1

Onboard

1

(for 2.5” HDD)

1

cPCI-3615P

Faceplate

2

4

1

1

1

1

1

Onboard

1

(for 2.5” HDD)

1

1

RTM

cPCI-R3610(T)

Faceplate

1

2

Onboard

2

(7-pin)

LAN

SATA

USB

VGA

COM

4-8

7

2

1

3

4

5

6

9

8
