background image
5
DC CHARACTERISTICS
Symbol
Parameter Description
Test Conditions
Min.
Typ.
Max.
Unit
VCC
Operating Voltage
3.0
4.5
5.0
V
ISB
Standby Current
Vcc = 3.0V, I/O Open
—
1
5
µA
IOP
Operating Current
Vcc = 3.0V, I/O Open
—
—
100
µA
VIH
Input HIGH Voltage
Vcc = 3.0V
2.5
3.0
3.5
V
VIL
Input LOW Voltage
Vcc = 2.0V
–0.3
0
0.3
V
IOH
VOUT HIGH Operating Current
Vcc = 3.0V, VOUT = 3.0V
—
–12
—
mA
IOL
VOUT LOW Operating Current
Vcc = 3.0V, VOUT = 0V
—
12
—
mA
ICO
COUT Operating Current
Vcc = 3.0V, VCOUT = 0.7V
—
–2
—
mA
ISTPH
STP HIGH Operating Current
Vcc = 3.0V, VSTP = 3.0V
—
–5
—
mA
ISTPL
STP LOW Operating Current
Vcc = 3.0V, VSTP = 0V
—
5
—
mA
ILED
LED Output Current
Vcc = 2.2V – 6.0V
6
8
10
mA
ÐF/F
Frequency Stability
(FOSC [3V] – FOSC [3.5V]) / FOSC (3.0V)
——
5
%
SAMPLING FREQUENCY vs
ROSC FOR API8208A
Common Sampling Rate vs. Oscillator Resistor
Sampling Frequency
ROSC
KHz
Kohm
5.0
290
5.5
262
6.0
240
6.5
220
7.0
201
7.5
187
8.0
174
8.5
162
9.0
153
9.5
143
10.0
135
10.5
127
11.0
120
12.0
108
SAMPLING FREQUENCY vs
ROSC FOR API8208A
Common Resistors vs. Sampling Rate
Sampling Frequency
Rosc
KHz
KOhm
13.0
100
14.0
91
16.0
82
22.0
54
