Data Sheet

AD590

Rev. G | Page 3 of 16

SPECIFICATIONS

AD590J AND AD590K SPECIFICATIONS

Table 1.

AD590J2

AD590K

Parameter

Min

Typ

Max

Min

Typ

Max

Unit

POWER SUPPLY

OperatingVoltage Range

4

30

4

30

V

OUTPUT

Nominal Current Output @ 25°C (298.2 K)

298.2

298.2

µA

Nominal Temperature Coefficient

1

1

µA/K

CalibrationError @ 25°C

±5.0

±2.5

°C

Absolute Error (Over Rated Performance Temperature Range)

Without External CalibrationAdjustment

±10

±5.5

°C

With25°C CalibrationError Set to Zero

±3.0

±2.0

°C

Nonlinearity

For TO-52 and FLATPACK Packages

±1.5

±0.8

°C

For 8-Lead SOIC Package

±1.5

±1.0

°C

For 4-Lead LFCSP Package

±1.5

°C

Repeatability3

±0.1

±0.1

°C

Long-Term Drift4

±0.1

±0.1

°C

Current Noise

40

40

pA/√Hz

Power Supply Rejection

0.5

0.5

µA/V

0.2

0.2

µV/V

0.1

0.1

µA/V

Case Isolation to Either Lead

Ω

Effective Shunt Capacitance

100

100

pF

Electrical Turn-On Time

20

20

µs

Reverse Bias Leakage Current (Reverse Voltage = 10 V)5

10

10

pA

1

Specifications shown in boldface are tested on all production units at final electrical test. Results fromthose tests are used to calculate outgoing quality levels. All

minimum and maximum specifications are guaranteed,although only those shown in boldfaceare tested on all production units.

2

The LFCSP package has a reduced operating temperature range of −40°Cto +125°C.

3

Maximum deviation between +25°Creadings after temperature cycling between −55°Cand +150°C; guaranteed, not tested.

4

Conditions: constant 5 V, constant 125°C;guaranteed,not tested.

5

Leakage current doubles every 10°C.
