 3 / 3 page
background image
CREAT BY ART
DIMENSIONS
Min
Max
Min
Max
A
3.00
3.40
0.118
0.134
B
1.30
1.70
0.051
0.067
C
0.35
0.75
0.014
0.030
D
0.75
0.95
0.030
0.037
Document Number：DS_S1311001
Version：J13
TS4148 RXG
Taiwan Semiconductor
Small Signal Product
DIM.
Unit(mm)
Unit(inch)
1
10
100
1000
10000
0.01
0.10
1.00
10.00
100.00
Forward Current (mA)
Fig. 5 Forward Resistance VS. Forward Current
