TS19702
High Power Factor Corrector LED Driver
3/9
Version: A12
Function Block
Pin Description
Pin No.
Name
Function
1
VCC
Power supply pin
2
GND
Ground pin
3
OUT
The output driver for driving the external MOSFET
4
DIM
Dimming control pin by input a DC voltage
5
COMP
Feedback compensation network
6
CS
Current sense pin, connect to sense the MOSFET current
