Series G3T

Process Sealed Ultra-Miniature SMT Toggles

www.nkk.com

A47

A

PACKAGING (CONTINUED)

Tape-Reel Packaging for Right Angle Mount

Each tape-reel of 550 pockets contains 500 switches.

Minimum Leader Length: 7.87” (200mm) Minimum Trailer Length: 1.97” (50mm)

Reel Dimensions

Tape Dimensions

Stick-Tube Packaging for Upright Mount

Each stick-tube contains 50 switches.

L = Length

G3T Upright (code P)

18.31” (465mm)

G3T Upright with Bracket (code B)

21.26” (540mm)

Stick-Tube Dimensions

(78.49) Dia

3.090

(2.0)

.079

(24.4)

.961

(13.0) Dia

.512

(2.0) Typ

.079

(21.0) Dia

.827

Overall Dia (330.0)

13.0

Terminal #1

Part No.

Direction of Feed

(2.1) Dia Typ

.083

(1.5) Dia Typ

.059

(4.0) Typ

.157

(16.0) Typ

.630

(2.0) Typ

.079

(1.75)

.069

(11.5)

.453

(24.0)

.945

(6.0)

.236

(0.4)

.016

(17.8)

.701

(8.6)

.339

(13.9)

.547

(1.5) R

.059

(2.0)

.079

(9.8)

.386

(15.3)

.602

(7.7)

.303

L
