OLED Display

www.nkk.com

E2

E

DISTINCTIVE CHARACTERISTICS

• Organic LED technology

• Power consumption only 2.4mA (30% less than previous product)

• Range of 65,536 colors in 16 bit mode, 256 colors in 8 bit mode

• Full viewing angle of 180°

• Exceptional contrast: 50 times greater than LCD products

• Four times more enhanced resolution

• High resolution provides sharp, clear images of very small characters

• Operated by commands and data supplied via serial communications (SPI)

• Dust tight construction

Viewing area: 12.9mm x 9.9mm (horizontal x vertical)

High resolution of 52RGB x 36 pixels

Bracket has crimped legs to ensure secure PC mounting

and prevent dislodging during wave soldering

Actual Size
