F2967

Preliminary

LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

4 of 9

www.unisonic.com.tw

QW-R109-036.a



PARAMETER

SYMBOL

RATINGS

UNIT

18

V

Maximum Output Current

50

mA

Output Withstand Voltage

18

V

HB Maximum Output Current

HB

10

mA

VTH Input Pin Withstand Voltage

8

V

RD/FG Output Pin Output Withstand Voltage

18

V

RD/FG Output Current

10

mA

Allowable Power

Dissipation

Mounted on a specified board (Note 2)

800

mW

Operating Temperature

-30~+95

°C

Storage Temperature

-55~+150

°C

Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. Mounted on a specified board (114.3mm×76.1mm×1.6mm, Glass epoxy)



PARAMETER

SYMBOL

RATINGS

UNIT

6~16

V

VTH Input Level Voltage Range

Full Speed Mode

0~7

V

Hall Input Common Phase Input Voltage Range

0.2~3

V



PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Circuit Current

During Drive

6

10

14

mA

During Lock Protection

6

10

14

mA

6VREG Voltage

5.80

6.0

6.15

V

VOVER Voltage

12.0

12.8

13.6

V

CPWM-H Voltage

4.35

4.55

4.75

V

CPWM-L Voltage

1.45

1.65

1.85

V

CPWM Oscillation Frequency

C=100pF

18

25

32

kHz

CT Pin H Voltage

3.4

3.6

3.8

V

CT Pin L Voltage

1.4

1.6

1.8

V

ICT Pin Charge Current

1.6

2.0

2.5

μA

ICT Pin Discharge Current

0.16

0.20

0.28

μA

ICT Charge/Discharge Current Ratio

8

10

12

deg

OUT-N Output Voltage

4

10

V

OUT-P Sink Current

15

20

mA

Sensitivity of Hall Input

Zero Peak Value (Including

Offset and Hysteresis)

10

20

mV

RD/FG Output Pin L Voltage

0.15

0.3

V

RD/FG Output Pin Leak Current

30

μA
